Covestro has launched the new Desmopan 7000 thermoplastic polyurethane (TPU). It exhibits high transparency for 5G frequencies, thus reducing signal losses. The product is therefore highly suitable for 5G applications, for example in protective covers for cell phones.

In comparison to the previous 4G standard, 5G technology enables higher network speeds, shorter data runtimes (latency), lower power consumption and more stable connections.

In order for users to reap the full benefits, devices must be equipped with cases that transmit signals with as little interference as possible. This is especially true for the thin protective covers of smartphones. In this application, the low dielectric constant (Dk) and low dielectric loss (Df) of the new TPU series prove to be beneficial.

Besides, products of the Desmopan 7000 series perform inherent shock- and vibration-absorbing properties, which are typical of TPU plastics. They also feature good abrasion resistance and flexibility over a wide temperature range, as well as good elasticity across the entire hardness range. Cell phones that are equipped with them are therefore also well protected against mechanical impact.

The new Desmopan 7000 is suited for 5G applications, for example in protective covers for cell phones.

In product developments, the fact that the TPU adheres well to other plastics such as polycarbonate or acrylonitrile butadiene styrene (ABS) is a major advantage.

Multilayer films for robust backsides

Smartphones for 5G reception require more space for antennas than their previous counterparts, and manufacturers must also replace metallic backs with other materials to ensure uninterrupted data exchange. Makrofol SR multilayer polycarbonate films with an acrylic top layer are suitable for requirements such as these. They are permeable to 5G radio signals and mechanically robust.

Moreover, they offer a great deal of design freedom: The films can be used to create cost-effective, attractive back covers with a look comparable to that of glass. Various technologies are available for this purpose, such as fine 3D structuring, non-conductive vacuum metallization, screen printing, letterpress molding and others.

Polycarbonate for modern radomes

In addition, the development of the 5G infrastructure entails a tightly meshed network of new, increasingly complex antennas. To protect the outer domes – the radomes – from the effects of the weather, Covestro has developed impact-modified polycarbonates that feature very good mechanical performance even at low temperatures, UV resistance, and design flexibility owing to their high processability.

They offer low Dk and Df values that ensure homogeneity in signal transmission and protect state-of-the-art electronics in active antenna units, micro-base stations and routers during outdoor use - throughout their ten-year service life.
