Dr. Boy GmbH & Co. KG will be presenting all seven exhibits in their new design for the first time at Fakuma 2026. In addition to the electromechanical models, all servo-hydraulic injection molding machines have now also been updated to the new design.

Visitors will see four automated exhibits that demonstrate extremely small footprint, three further injection molding machines at partner booth, as well as a representative cross-section of Boy’s entire product portfolio.

Boy’s Electric Barista features BOY 50 Electric, a collaborative robot.

New LR 5 Compact linear handling system

Highlight will be the new LR 5 Compact linear handling system. In this space-saving solution, the LR 5 Compact, including the conveyor belt, is fully integrated below the protective cover of the BOY 35 Electric – without any additional safety fence and, consequently, without the need for EM67 and EM78.

The footprint is reduced from approximately 5.2 to 3.1 m² compared to a machine with an external protective enclosure, with a required ceiling height of just 2.6 m. The entire unit remains fully transportable.

The LR 5 Compact is controlled via the Procan ALPHA 6 machine control system and is therefore fully integrated. This not only simplifies the process set-up itself but also enables integrated data and error management.

During the production of oil pourers, the new "electromechanical unscrewing" option will also be presented.

Electric Barista: Collaborative robot serves coffee in specially molded cups

Another highlight will be the Electric Barista. At the BOY 50 Electric, a collaborative robot will serve freshly prepared espressos in specially molded cups made from NAS 30 ECO.

BOY 100 Electric for silicone application

The third and largest electromechanical injection molding machine, the BOY 100 Electric, will be used for a silicone application. Here, foldable funnels are produced, which are placed onto a conveyor belt with the support of the integrated LR 5.

BOY’s electromechanical injection molding machines are synonymous with precise injection, high dynamics and reduced cycle times thanks to parallel movements. They also stand out for their optimum positioning accuracy and lubricant-free mold mounting area.

Micro-injection molding solutions

Furthermore, BOY is placing a focus on micro-injection molding and will present two of its smallest injection molding machines, the BOY XS E, side by side.

The two BOY XS E machines, each with a clamping force of 100 kN, are used to produce extremely small medical micro-parts that are almost invisible to the naked eye – one made from LSR and the other from a medical-grade PLA of the RESOMER LR 704 S type.

Each machine is equipped with a full-size 8 mm screw, which, as with all our machines, operates on a first-in, first-out basis.

Vertical BOY 35 E VV

On the vertical insert molding machine BOY 35 E VV with automation, tool star handles with HEX 3, 4 and 5 are produced within a minimal footprint. A flexible separation system from Variobotic is used, which is positioned directly on the machine frame to save space.

Entry-level model: BOY 20 E PRO

The exhibits are rounded off by the BOY 20 E PRO, on which so-called “battery beer crates” are produced. The small, injection-molded plastic beer crate serves as a practical storage box for batteries.

The BOY 20 E PRO is the entry-level model with its reduced range of features and the proven Procan ALPHA 4 control system. However, there are no compromises in terms of energy efficiency, as it utilizes the same servo-motor drive technology as all BOY injection molding machines in the E-Series.
